Sound Devices MM-1 microphone preampThis is the MM-1 Single channel mic. pre-amp from Sound Devices. It has a stepped gain control, limiter, bass cut filter, phantom and T powering, headphone amp. and monitor return input. that's quite a lot in a small box! Ideal for a boom op. or even just for providing phantom power. - Maximum of 66 dB of gain, in eleven discrete steps
- Dynamic range exceeding 120 dB
- 10 Hz to 50 kHz audio bandwidth
- High immunity to RF interference
- High current line output driver
- Transformer-balanced input and output
- Extended range peak limiter via dual opto-isolators makes preamplifier virtually “unclippable”
- Selectable 48-volt / 12-volt phantom power or 12-volt “T” power
- High-pass filter @ 80 or 160 Hz, 6 dB per octave
- Headphone monitoring of microphone audio, monitor audio, or a mix of both
- Monitor input accepts mono, balanced or unbalanced line-level inputs on 1/4 jack
- Separate level control of Monitor gain and overall headphone gain
- Split ear function via DIP switches
- Internal battery power (two-AA)
- Excellent battery life with alkaline and NiMH rechargeable batteries
- External 5-17 VDC powering
- High-strength aluminum chassis with durable belt clip
|
